The W-3005 is a weather resistant, handsfree video doorbox designed to provide quick and reliable handsfree communication and CCTV video of who is at your door or gate. The W-3005 can interface directly with the unused telephone line input of nearly any phone system. One or two doorboxes can also share an existing residential phone line when used with a C-1000B doorbox controller.

Handsfree Doorbox Features

• Built-in high resolution color video camera with wide viewing angle, tilt/swivel adjustments and wide operating temperature of -30°F to 150°F
• Audio and video transmission on one CAT5E cable
• Vandal Resistant Features: 14 gauge louvered stainless steel faceplate with stainless steel speaker/mic screen, heavy duty metal “Call” button, impact and scratch resistant camera lens and hex drive mounting screws
• Weather Resistant Features: Mylar speaker, faceplate gasket, microphone and speaker gasket, internally sealed (IP67) push button switch, sealed camera lens, potted camera circuit board, stainless steel phone and camera mounting hardware
• Optional Enhanced Weather Protection (EWP) conforms to NEMA requirements
• Volume adjustments for microphone and speaker
• Yellow call progress/night light LED
• High output speaker amplifier with volume adjustment POT 20 Hz ring generator (3.0 REN ring load maximum)
• Selectable ring cadence (standard or 2 short rings)
• Selectable number of rings (2, 3, 10 or 30)
• Selectable “Push-to-Talk” feature for noisy environments
• Optional VE-5x5 surface mount box available

Enhanced Weather Protection Option:

Includes weather-sealed trim pots and DIP switches, a special rubber microphone boot and a mylar speaker with a rubber gasket acting as a primary shield against water penetration. If required, face plate gaskets are provided to further eliminate water infiltration. All connections are hand soldered to eliminate corrosion, and the connections at the push button switch, microphone, and "Call Connected" LED are also hand sealed using a special non-corrosive electronics grade flexible silicone sealant. The entire circuit board is "potted" in a flexible urethane encapsulating material, leaving the weather sealed field-adjustable trim pots and DIP switches accessible for on-site programming. The flexible urethane sealant allows the circuit board and its components to expand and contract, while maintaining weather resistance. To protect the tip and ring connections, special connectors filled with anti-corrosive sealing gel are included.

SKU	Weather Protection
W-3005	Standard
W-3005-EWP	Enhanced
