Viking 30 Watt 8 Ohm 70 Volt Paging Horn

(Model # 300AE)
Viking 30 Watt 8 Ohm 70 Volt Paging Horn
Viking

Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.

  • $87.58

  • Availability:
  • In Stock
  • Manufacturer
  • 2 Year Limited Warranty
Qty:
The 300AE paging horn provides a direct voice coil connection for use with Viking 8 ohm paging systems. The 300AE paging horn also provides a built-in step-down transformer for use with 25V or 70V paging systems such as Viking models PA-30 and PA-60. The transformer has a range of power taps that are selectable with a 6 position rotary switch.
300Ae Features:
  • Large 10 inch diameter horn
  • 30 watt power handling
  • Direct 8 ohm connection or step-down transformer connection
  • Compatible with 25V or 70V paging systems
  • Weather resistant rugged gray plastic housing
  • Fully adjustable mounting hardware included
  • Wide frequency response
  • Greater intelligibility of voice pages
  • Suitable for background music
  • High efficiency
Specifications:
  • Power Handling: 30 Watts
  • Direct Impedance: 8 Ohms
  • 70V Taps: 4W, 8W, 15W, and 30W
  • 25V Taps: .5W, 1W, 2W, 4W, 8W, and 15W
  • Viking Taps: 1W, 2W, 4W, 8W, 15W, and 30W
  • Frequency Response: 300 Hz to 9000 Hz
  • Sound Pressure Level: 107dB 1W/1m, 117dB 30W/1m
  • Dimensions: 254mm (10”) diameter, 292mm (11.5”) Long
