Legrand - Wiremold OmniBox Series Two-Gang Stamped Steel Floor Box

(Model # 880S2)
Legrand - Wiremold OmniBox Series Two-Gang Stamped Steel Floor Box
Legrand - Wiremold

Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.

  • $100.36

  • Availability:
  • Usually ships in 10 days
Two-Gang stamped steel floor box is fully adjustable. The Omnibox Floor Box Series provides an excellent activation solution when multiple services are required in open space areas.
880S2 Features:
  • TopGuard protection: All cover assemblies for the Omnibox Floor Box Series have TopGuard protection. An integral design which keeps out water, dirt, and debris from the power and communication compartments
  • Concrete-tight stamped steel construction: Lower cost option for above grade applications
  • Flush activation assemblies for carpet and tile: Aesthetically pleasing assemblies are interchangeable for both cast-iron and stamped steel
  • Watertight cast-iron construction. Meets requirements for on grade or below grade application
  • Cubic Inch Capacity of 117
  • Two-gang configurations, maximum flexibility. Can remove divider for greater capacity. Supports multiservice applications
  • Conduit Openings - (4) 1/2" [12.7mm], (8) 3/4" [19.1mm](4) 1" [25mm]
  • Fully adjustable box: Before and after concrete pour adjustability. Lower installed cost
  • Adjustment Before Pour 1 3/4" [44mm]
  • Adjustment After Pour 1/2" [12.7mm]
  • Dimensions - 7 15/16" L x 4 13/16" W x 3 15/32" H
  • Boxes and covers have been listed by Underwriters Laboratories Inc. to their standard UL514A, 514C, 514D, and Canadian standard C22.2
  • Datacom connectivity options. Accepts industry standard and proprietary devices from a wide range of manufacturers to provide a seamless and aesthetically pleasing interface for voice, data, audio, and video applications at the point-of-use. A wide selection of data and bezel options available for use with Ortronics TracJack and Series II devices
