Leviton GigaMax 5e QuickPort Channel-Rated Connector Quickpack
(Model # 5G108-B)
Product Brochure (pdf)
Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.
Modular connector for Category 5e UTP structured cabling systems. Uses include high megabit applications such as Gigabit Ethernet and 622 Mbps ATM.
GigaMax 5e Connector Features:
- Dual wiring code label allows connector to be wired to either T568A or T568B
- Individual port configurability allows specification flexibility
- Robust one-piece lead-frame design
- Narrow connector allows high port density in a small area
- Performance supports high megabit and shared-sheath applications
- Use in any quickport housing to support GigaMax (category 5e) UTP connectivity in surface mount, flush mount, or modular furniture outlets, or patch panels and patch blocks
- Can be used in conjunction with other quickport snap-in modules for voice/data and video applications over UTP, coax and fiber
- To ID ports, use different colored modules for each application
- UL listed
- Complies with all TIA/EIA-568-B requirements
- Meets FCC Part 68
- Connector Body Material: High-impact, fire-retardant plastic rated UL 94V-0
- Spring Wire Contacts Material: High-quality phosphor bronze, plated with 50 micro-inches of gold over 100 microinches of nickel for lowest contact resistance, maximum life
- Connector 110-style IDC Contacts Material: Solder-plated phosphor bronze
| SKU | Quantity | Color |
|---|---|---|
| 5G108-RE5 | Single | Black |
| 5G108-RL5 | Single | Blue |
| 5G108-RB5 | Single | Brown |
| 5G108-RC5 | Single | Crimson Red |
| 5G108-RR5 | Single | Dark Red |
| 5G108-RG5 | Single | Gray |
| 5G108-RV5 | Single | Green |
| 5G108-RI5 | Single | Ivory |
| 5G108-RO5 | Single | Orange |
| 5G108-RY5 | Single | Yellow |
| 5G108-BE5 | Pack of 25 | Black |
| 5G108-BL5 | Pack of 25 | Blue |
| 5G108-BB5 | Pack of 25 | Brown |
| 5G108-BR5 | Pack of 25 | Dark Red |
| 5G108-BG5 | Pack of 25 | Gray |
| 5G108-BV5 | Pack of 25 | Green |
| 5G108-BI5 | Pack of 25 | Ivory |
| 5G108-BO5 | Pack of 25 | Orange |
| 5G108-BY5 | Pack of 25 | Yellow |
| 5G108-BC5 | Pack of 25 | Crimson Red |
