Bogen Ceiling Speaker
(Model # CS1EZ)
Product Brochure (pdf)
Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.
The Bogen CS1EZ is a pre-assembled 1-watt single-tap ceiling speaker designed for use with 70V amplifier
systems.
CS1EZ Features:
- 1-watt single tap design
- Screw terminal connections for fast installation
- Works with 70V amplifier output
- 8" cone speaker for excellent audio quality
- Heavy-duty wire-wound volume control with knob
- Pre-assembled for faster installation
- Volume knob and rear mounted screw terminal board for easier connection
- Frequency Response: 50 Hz to 12 kHz
- Impedance: 4900 ohms (for use on 70V amplifier outputs)
- Sound Pressure Level: 95 dB @ 4 ft. with a 1-watt input on axis
