Allen Tel Weather Resistant Speakerphone with Automatic Dialer

(Model # GB32390SND)
Allen Tel Weather Resistant Speakerphone with Automatic Dialer
Allen Tel

Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.

  • $733.57

  • Availability:
  • Usually ships in 48 hours
Qty:
Constructed of a high impact polycarbonate material. These new weather resistant telephones are particularly suited for ADA compliant applications on university and college campuses, commercial buildings, hospitals, airports, etc.

Note: Not recommended for temperatures below -5F (-20C).

Features:
  • Remote programmable
  • Auto Answer
  • Braille Labels
  • Push Button to operate
  • Two Minute disconnect
  • Single number autodialer for emergency dialing
  • Braille labels and ID Tones for location identification
  • 2 Led Lamps to indicate "ON" and "HELP ON THE WAY
  • Speakerphone is constructed of high impact polycarbonate material
I) Programming

Speakerphone must be programmed remotely from a separate line, using any Touchtone Telephone.

  • Note: During program mode, a beep must be heard before programming, phone can be disconnected at any time by pressing *, #, *, *.

    1. To Program Auto Dial (SND)
      Press #, #, 9, enter phone number *, #.
    2. To Program Auto Dial behind a PBX
      Press #, #, 9, 9, #, 03, enter phone number, *, #.
    3. To Program Auto Dial with ID Tones
      Press #, #, 9, enter phone number, #, 15, enter ID number, *, #.
    4. To Dial a Second Number on Busy Tone, or No Answer
      Press #, #, 9, enter first phone number, *, 5, enter second phone number, *, 63, *, #.
    5. To Re-Dial on Busy Tone or No Answer
      Press #, #, 9, enter phone number, *, 63, *, #. (Re-dial 3 times)
    6. To set Receiving Level
      Press #, #, 61, XX, *, #. (Where XX= between 00 and 99)
    7. To Set Transmit Level
      Press #, #, 62, XX, *, #. (Where XX= between 00 and 99)
    8. Length of Call (Default=2 Minutes)
      Press #, #, 63, XX, YY, *, #. (Where XX- Minutes and YY= Seconds)

    II) How to set your Security Code (optional) by default, phone has no security code setting.

    Press #, #, 76, #, 65, enter 4-digit code, *, #. (If used, remember the numbers)

    III) How to Deactivate the security code

    Press #, enter your 4-digit code, #, 76. (1 beep + 3 beeps= Deactivate)

    IV) Programming Example (with Security code)

      To Program Auto Dial (with security code)
      Press #, enter your 4-digit code, #, 9, then enter phone number, *, #.
