Allen Tel Ring Down Outdoor Phone with Amplified Handset and Push Latch

(Model # GB90VNXX)
Allen Tel Ring Down Outdoor Phone with Amplified Handset and Push Latch
Allen Tel
Ring Down Phone Only!

Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.

  • $549.87

  • Availability:
  • Usually ships in 3 weeks
  • Color
  • Handset Cord
  • Text
  • Door Hinge
  • Door Lock
  • Returnable
  • Due to the specialized nature of this product it is Not Returnable
  • Warranty
  • 1 Year Limited Warranty
Qty:
Weather Resistant Housing Single Line No Dial Phone is designed to be used with auto ring down circuits. Telephones are particularly suited for use on College Campuses as well as Airports, Parking Garages, and Industrial Locations.
Single Line Telephone Features:
  • GB90H Weather resistant housing constructed of die cast aluminum with gaskets, electrostatically deposited tough enamel finish
  • GB59VN-LH single line stainless steel panel telephone with hearing aid compatible amplified handset
  • Standard transmitter
  • No dial pad
  • Used on ring down circuit or hot line dialer
  • Tamper resistant screws and wrench included
  • Available Colors:
    • Black
    • Red
    • Yellow
    • Gray
  • Handset Cord:
    • 6 foot Coiled cord
    • 14 inch Armored cord
  • Door Hinge Configuration:
    • Standard
    • Spring Loaded
  • Door Lock Options:
    • Plastic Push Latch (Always Unlocked)
    • Plastic Push Latch with Metal Keys (Can be left Unlocked or Locked)
    • Metal Push Latch with Metal Keys (Always Locked)
  • Logo Text Options for Door Enclosure:
    • EMERGENCY
    • TELEPHONE
Available Options:
Model # GB5955PMB Pole Mounting Bracket
Model # K-1900-5 Hotline Dialer

NOTE: Product is delivered with a Standard Transmitter. A Noise Canceling Transmitter is also available - Please Call for Pricing

Quality, reliability and durability - three reasons why AllenTel Weatherproof telephones have been successful for over 45 years. The housings are constructed of die cast aluminum and electrostatically deposited tough enamel finish. The hardware on the GB5955H housing includes a stainless steel hasp latch, which will also accept a padlock. The GB90 Series of telephones uses a newly designed housing incorporating either a push latch or a push key lock. All housings are equipped with gaskets and the Legend Telephone.

The Variety of complete telephone models offered includes speaker phones and single line units using pulse, tone or automatic dialing. Replacement telephone sets are available with out housing.

AllenTel's full line of Weatherproof/Emergency telephones are particularly suited for use on college campuses, airports, parking garages and industrial locations. Speakerphone models may not operate properly in environments with high ambient noise levels. In those areas we recommend our handset models featuring an armored cord. In accordance with FCC regulations, all handsets furnished with AllenTel Weatherproof telephones are equipped with hearing aid compatible, amplified receivers.

Need to know the exact dimensions of AllenTel's weatherproof enclosures? Click Here for the full specifications.

Note: All tel sets are equipped with amplified handset and 29" amored cord.

Example: The GB92V-00 consists of GB90 housing with telephone legend on door and a single line panel mounted tel set. Includes a 6 foot black coil cord, amplified receiver, and standard plastic dial. Equipped with GBH4WP 14" Armored Cord (29" Armored Cord included on all GB70V/72V Series tel sets). Note: The K lock is constructed of high impact plastic. For special key applications please contact the factory.


AllenTel ADA Weatherproof Telephones

AllenTel ADA products meet or exceed current AMERICANS WITH DISABILITIES ACTS requirements and feature amplified receivers per FCC regulations.

The GB70 Series Telephones are offered in three models. The GB70VS featuring an automatic single number dialer, the GB70VN, particularly suited for automatic ring down circuit and the GB73V model with a 12 button tone dial.

The weatherproof housing is constructed of die cast aluminum and electrostically deposited tough enamel finish. The GB70H housing incorporates a push key lock. The push latch may be disengaged in order to meet local ADA requirements. All housings are equipped with gaskets.

All models include:

  • Handset with a 29" armored cord
  • Amplified receiver
  • Spring loaded door
  • Braille labes
  • ID tones
  • 2 LED lamps

Note: All GB70H housings feature a spring loaded door. XX denotes housing color- 00 Black, 02 Red, 04 Yellow, 14 Gray, Other colors available on special order.


Specifications:

The GB31932 Steel Protective Cover measures 12" H X 10" W X 4" D and will accept most telephone sets. Finished in red baked enamel.

The GB31858 Weatherproof System Phone Enclosure is designed to provide protection for outdoor installations against rain, sleet and snow. Accepts most features and key system wall mountable telephones. A plywood backboard with mounting holes for the "optional" GB5955LAF Adapter Frame Bracket bracket is provided with this enclosure. Meets NEMD/EEMAC type 3R, UL50 type 3R, CSA enclosure 3, IEC529, IP32. The standard color is red enamel.

The GB5955LAF Adapter Frame Bracket is designed to mount a standard single line wall or mini wall phone in the GB5955H and GB90H housings.

SKU Color Handset Cord Text Door Hinge Door Lock
GB90VN00Y Black 6 Foot Coiled EMERGENCY Standard Plastic Push Latch
GB90VN00YK Black 6 Foot Coiled EMERGENCY Standard Plastic Push Latch with Keys
GB90VN00YW Black 6 Foot Coiled EMERGENCY Standard Metal Push Latch with Keys
GB90VN00YP Black 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch
GB90VN00YPK Black 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN00YPW Black 6 Foot Coiled EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN00 Black 6 Foot Coiled TELEPHONE Standard Plastic Push Latch
GB90VN00K Black 6 Foot Coiled TELEPHONE Standard Plastic Push Latch with Keys
GB90VN00W Black 6 Foot Coiled TELEPHONE Standard Metal Push Latch with Keys
GB90VN00P Black 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch
GB90VN00PK Black 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN00PW Black 6 Foot Coiled TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN00HY Black 14 Inch Armored EMERGENCY Standard Plastic Push Latch
GB90VN00HYK Black 14 Inch Armored EMERGENCY Standard Plastic Push Latch with Keys
GB90VN00HYW Black 14 Inch Armored EMERGENCY Standard Metal Push Latch with Keys
GB90VN00HYP Black 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch
GB90VN00HYPK Black 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN00HYPW Black 14 Inch Armored EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN00H Black 14 Inch Armored TELEPHONE Standard Plastic Push Latch
GB90VN00HK Black 14 Inch Armored TELEPHONE Standard Plastic Push Latch with Keys
GB90VN00HW Black 14 Inch Armored TELEPHONE Standard Metal Push Latch with Keys
GB90VN00HP Black 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch
GB90VN00HPK Black 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN00HPW Black 14 Inch Armored TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN02Y Red 6 Foot Coiled EMERGENCY Standard Plastic Push Latch
GB90VN02YK Red 6 Foot Coiled EMERGENCY Standard Plastic Push Latch with Keys
GB90VN02YW Red 6 Foot Coiled EMERGENCY Standard Metal Push Latch with Keys
GB90VN02YP Red 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch
GB90VN02YPK Red 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN02YPW Red 6 Foot Coiled EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN02 Red 6 Foot Coiled TELEPHONE Standard Plastic Push Latch
GB90VN02K Red 6 Foot Coiled TELEPHONE Standard Plastic Push Latch with Keys
GB90VN02W Red 6 Foot Coiled TELEPHONE Standard Metal Push Latch with Keys
GB90VN02P Red 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch
GB90VN02PK Red 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN02PW Red 6 Foot Coiled TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN02HY Red 14 Inch Armored EMERGENCY Standard Plastic Push Latch
GB90VN02HYK Red 14 Inch Armored EMERGENCY Standard Plastic Push Latch with Keys
GB90VN02HYW Red 14 Inch Armored EMERGENCY Standard Metal Push Latch with Keys
GB90VN02HYP Red 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch
GB90VN02HYPK Red 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN02HYPW Red 14 Inch Armored EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN02H Red 14 Inch Armored TELEPHONE Standard Plastic Push Latch
GB90VN02HK Red 14 Inch Armored TELEPHONE Standard Plastic Push Latch with Keys
GB90VN02HW Red 14 Inch Armored TELEPHONE Standard Metal Push Latch with Keys
GB90VN02HP Red 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch
GB90VN02HPK Red 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN02HPW Red 14 Inch Armored TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN04Y Yellow 6 Foot Coiled EMERGENCY Standard Plastic Push Latch
GB90VN04YK Yellow 6 Foot Coiled EMERGENCY Standard Plastic Push Latch with Keys
GB90VN04YW Yellow 6 Foot Coiled EMERGENCY Standard Metal Push Latch with Keys
GB90VN04YP Yellow 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch
GB90VN04YPK Yellow 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN04YPW Yellow 6 Foot Coiled EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN04 Yellow 6 Foot Coiled TELEPHONE Standard Plastic Push Latch
GB90VN04K Yellow 6 Foot Coiled TELEPHONE Standard Plastic Push Latch with Keys
GB90VN04W Yellow 6 Foot Coiled TELEPHONE Standard Metal Push Latch with Keys
GB90VN04P Yellow 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch
GB90VN04PK Yellow 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN04PW Yellow 6 Foot Coiled TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN04HY Yellow 14 Inch Armored EMERGENCY Standard Plastic Push Latch
GB90VN04HYK Yellow 14 Inch Armored EMERGENCY Standard Plastic Push Latch with Keys
GB90VN04HYW Yellow 14 Inch Armored EMERGENCY Standard Metal Push Latch with Keys
GB90VN04HYP Yellow 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch
GB90VN04HYPK Yellow 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN04HYPW Yellow 14 Inch Armored EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN04H Yellow 14 Inch Armored TELEPHONE Standard Plastic Push Latch
GB90VN04HK Yellow 14 Inch Armored TELEPHONE Standard Plastic Push Latch with Keys
GB90VN04HW Yellow 14 Inch Armored TELEPHONE Standard Metal Push Latch with Keys
GB90VN04HP Yellow 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch
GB90VN04HPK Yellow 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN04HPW Yellow 14 Inch Armored TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN14Y Grey 6 Foot Coiled EMERGENCY Standard Plastic Push Latch
GB90VN14YK Grey 6 Foot Coiled EMERGENCY Standard Plastic Push Latch with Keys
GB90VN14YW Grey 6 Foot Coiled EMERGENCY Standard Metal Push Latch with Keys
GB90VN14YP Grey 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch
GB90VN14YPK Grey 6 Foot Coiled EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN14YPW Grey 6 Foot Coiled EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN14 Grey 6 Foot Coiled TELEPHONE Standard Plastic Push Latch
GB90VN14K Grey 6 Foot Coiled TELEPHONE Standard Plastic Push Latch with Keys
GB90VN14W Grey 6 Foot Coiled TELEPHONE Standard Metal Push Latch with Keys
GB90VN14P Grey 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch
GB90VN14PK Grey 6 Foot Coiled TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN14PW Grey 6 Foot Coiled TELEPHONE Spring Loaded Metal Push Latch with Keys
GB90VN14HY Grey 14 Inch Armored EMERGENCY Standard Plastic Push Latch
GB90VN14HYK Grey 14 Inch Armored EMERGENCY Standard Plastic Push Latch with Keys
GB90VN14HYW Grey 14 Inch Armored EMERGENCY Standard Metal Push Latch with Keys
GB90VN14HYP Grey 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch
GB90VN14HYPK Grey 14 Inch Armored EMERGENCY Spring Loaded Plastic Push Latch with Keys
GB90VN14HYPW Grey 14 Inch Armored EMERGENCY Spring Loaded Metal Push Latch with Keys
GB90VN14H Grey 14 Inch Armored TELEPHONE Standard Plastic Push Latch
GB90VN14HK Grey 14 Inch Armored TELEPHONE Standard Plastic Push Latch with Keys
GB90VN14HW Grey 14 Inch Armored TELEPHONE Standard Metal Push Latch with Keys
GB90VN14HP Grey 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch
GB90VN14HPK Grey 14 Inch Armored TELEPHONE Spring Loaded Plastic Push Latch with Keys
GB90VN14HPW Grey 14 Inch Armored TELEPHONE Spring Loaded Metal Push Latch with Keys
