Viking 15 Watt Paging Amp with Background Music
(Model # PA-15)
Product Brochure (pdf)
Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.
Viking PA-15 15 Watt Paging Amp with Background Music.
PA-15 Features:
- 15 Watts of paging power
- Drive up to (15) 8-ohm speakers
- 600 Ohm output to drive additional amplifiers
- Select: FXO (loop start), FXS (ring trip) or paging port (VOX relay) interface mode
- Independent volume controls for Paging, Ringing Tones and Background Music
- 36V DC talk battery for interfacing with FXO or unused phone system line input/trunk port
- Compatible with 24V to 48V FXS (ring trip) analog station operation
- 800 Hz pre-announce page tone (on/off)
- Provides Night Bell warble tone via contact closure or independent ringing analog circuit
- Night transfer switch input
- CPC detection for immediate disconnect
- Busy signal detect disconnect
- Adjustable silence time out disconnect
- Programmable VOX trigger sensitivity and time out
- 16 to 72 second (or off) default disconnect timer
- Choice of four ringing sounds:
- Electronic warble (traditional loud ringer)
- Double gong (two identical gong tones)
- Quadruple chime (four descending chime tones)
- Door chime (ding-dong)
Note:
- Analog terminal adapter required for VoIP applications
