Bogen Call-in Module
(Model # SCR25A)
Product Brochure (pdf)
Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.
Call-In Module is an annunciator latching control bank designed for use with room selector panels in Multi-Graphic systems. The silicon controlled rectifiers provide annunciator latching, keeping the appropriate LED annunciator lamp on the room selector panel illuminated until the call is acknowledged.
Features:
- Provides 25 silicon controlled rectifiers
- Permits the use of momentary switches without SCRs
- Provides annunciator latching control
- Simple plug-in method
- 25 annunciator circuit capacity
- Operating mode set with jumpers
- Termination via centerline pins (use Bogen 25-Series Connector Kit)
- Support brackets included
