Quick Reference for SND Speakerphone Models

I) Programming

allen tel, allen tel SND, Allen Tel Speakerphone Speakerphone must be programmed remotely from a separate line, using any Touchtone Telephone.

This reference works with the following phones:

Note: During program mode, a beep must be heard before programming, phone can be disconnected at any time by pressing *, #, *, *.

To Program Auto Dial (SND)
Press #, #, 9, enter phone number, *, #.
To Program Auto Dial behind a PBX
Press #, #, 9, 9, #, 03, enter phone number, *, #.
To Dial a Second Number on Busy Tone, or No Answer
Press #, #, 9, enter first phone number, *, 5, enter second phone number, *, 63, *, #.
To Re-Dial on Busy Tone or No Answer
Press #, #, 9, enter phone number, *, 63, *, #. (Re-dial 3 times)
To set Receiving Level
Press #, #, 61, XX, *, # (Where XX= between 00 and 99)
To set Transmit Level
Press #, #, 62, XX, *, #. (Where XX= between 00 and 99)
Length of Call (Default=2 minutes)
Press #, #, 63, XX, YY, *, #. (Where XX=minutes and YY= seconds)

II) How to set your Security Code
(optional) by default, phone has no security code setting.

Press #, #, 76, #, 65, enter 4-digit code, *, #. (If used, remember the numbers)

III) How to Deactivate the security code

Press #, enter your 4-digit code, #, 76. (1 beep + 3 beeps= Deactivate)

IV) Programming Example (with Security code)

To Program Auto Dial

Press #, enter your 4-digit code, #, 9, then enter phone number, *, #.

Products

Outdoor Speakerphone w/Automatic Dialer/S.S. Hasp
(Model #GB25900SNDXX)

Outdoor Speakerphone w/Automatic Dialer
(Model #GB97SND)

Elevator/Hall Speakerphone w/Auto-Dialer/2 Minute Auto-Disconnect
(Model #GB555SND)

Mini-Elevator Speakerphone w/Automatic Dialer
(Model #GB31454-SND)

Outdoor Speakerphone w/Auto-Dial/No Housing
(Model #GB25900SND-LH)
