The CableCat Family

CableCat provides support of high-performance cabling including Category 5 and higher speed copper cable, Fiber optic and innerduct. A variety of sizes are available to accommodate up to 425 four-pair UTP. This is a cost effective alternative to cable trays. Factory or field made assemblies allow for attachment to virtually any structural member.

"The Original"

The first wide-base J-Hook assembly was specifically designed for high performance telecommunications cabling. The "original" CADDY CableCat J-Hooks, with 1-5/16" and 2 " diameter loops, have expanded into a comprehensive line of solutions for any application. The wide-base J-Hook provides proper support and routes cables with a sufficient bend radius to prevent pressure on cables.

Small Bundle Support

This new size was designed to comply with the current 1997 TIA standard 569-A, which allows for attachment to ceiling wire and grid. Factory assemblies are also available for attachment to other structures. The CAT12 size J-Hook holds up to 16 four-pair UTP or fiber optic cables and is equipped with a unique bend-back tab to provide containment without pressure on cables.

Large Bundle Support

Now providing the widest support available in the CableCat family, the new CAT425 can adjust to a 4" or 6" diameter loop. This flexible cable wrap can hold up to 425 four-pair UTP or fiber optic cables and quickly attaches to beams or purlins. It's simple locking and unlocking feature allows for the addition of cables without a hitch, and cables pull easily through the closed support system. This Cat is suitable for air handling spaces (plenum) for loads up to 100 lbs.

Underfloor Support

The CableCat J-Hook is now available for raised floor environments. Cables are easily organized off the floor and the wide-base J-Hook provides a cost-effective alternative to cable trays. This underfloor CableCat is pre-riveted to a fully assembled fastener ready to attach to the floor pedestal. Now from roof to floor, ERICO has a CADDY CableCat solution to fit.

---

CableCat Wide Base Cable Support

Features: Provides proper support of Category 5, fiber optic and innerduct Variety of sizes and designs available to attach to virtually any structure Cost effective alternative to expensive cable tray Galvanized finish on J-hooks provide smoother cable pull and greater corrosion resistance Complies with UL, cUL, NEC and EIA/TIA requirements for structured cabling systems

Sizing Chart
	Catalog Number	Description	QTY Per Box
	CAT12	Up to 16 4-pair UTP or 2-strand fiber optic cable - 3/4" dia. loop	50
	CAT21	Up to 50 4-pair UTP pr 2-strand fiber optic cable or innderduct 1-5/16" dia. loop	80
	CAT32	Up to 80 4-pair UTP or 2-strand fiber optic cable or innderduct 2" dia. loop	60
	CAT64	Up to 300 4-pair UTP or 2-strand fiber optic cable 4" dia. loop	25
	CATHBA	Angled hanger bracket	40
	S3575BP100	1/4" - 20 x 3/8" round head screw	100
	S3575DP100	1/4" - 20 x 3/4" round head screw	100
	CATTS	Support from tee grid	100

Kits for Category 5 Cable Hangers
	Description	QTY Per Box
CATKITA	(20) CAT32 (5) CATHBA Hanger (5) BC200 Beam Clamps	1 Kit
CATKITB	(10) CAT21 (10) CAT32 (5) CATHBA Hanger (5) BC200 Beam Clamps Screws included	1 Kit
CATKITC	(20) CAT21 (5) CATHBA Hanger (5) BC200 Beam Clamps Screws included	1 Kit

Pre-Riveted Factory Assemblies for 3/4
	Catalog Number	Description	QTY Per Box
	CAT12BC	Screw-on 1/8" thru 1/2" flange	40
	CAT12BC200	Screw-on 1/8" thru 5/8" flange	40
	CAT1224	Hammer-on 1/8" thru 1/4" flange - bottom mount rotates 360 degrees	40
	CAT1258	Hammer-on 5/16" thru 1/2" flange - bottom mount rotates 360 degrees	40
	CAT12912	Hammer-on 1/2" thru 3/4" flange - bottom mount rotates 360 degrees	20
	CAT12VF14	1/2" thru 1/4" vertical flange	40
	CAT12AF14	1/16" thru 1/4" Z Purlin	40
	CAT124Z34	#12 thru 1/4" wire, plain or threaded rod and 1/8" thru 3/8" flange	60
	CAT126Z34	3/8" plain or threaded rod and 3/8" thru 9/16" flange	60
	CAT12AFAB3	Angle bracket	80
	CAT12BCB	Screw-on 1/8" thru 1/2" flange - rotates 360 degrees	40
	CAT12BC200B	Screw-on 1/8" thru 5/8" flange - rotates 360 degrees	40
	CAT12TS	Acoustical tee bar	60
	CAT12CD1B	Under floor support to pedestal	20

Pre-Riveted Factory Assemblies for 1-5/16
	Catalog Number	Description	QTY Per Box
	CAT21528	Cable to acoustical tee bar	20
	CAT21BC	Screw-on 1/8" thru 1/2" flange	40
	CAT21BC200	Screw-on 1/8" thru 5/8" flange	40
	CAT2124	Hammer-on 1/8" thru 1/4" flange - rotates 360 degrees	40
	CAT2158	Hammer-on 5/16" thru 1/2" flange - rotates 360 degrees	40
	CAT21912	Hammer-on 1/2" thru 3/4" flange - rotates 360 degrees	20
	CAT21VF14	1/16" thru 1/4" vertical flange	40
	CAT21AF14	1/16" thru 1/4" Z purlin	40
	CAT214Z34	#12 thru 1/4" wire, plain pr threaded rod and 1/8" thru 3/8" flange	60
	CAT216Z34	3/8" plain or threaded rod and 3/8" thru 9/16" flange	60
	CAT12AFAB3	Angle bracket	50
	CAT21BCB	Screw-on 1/8" thru 1/2" flange - rotates 360 degrees	40
	CAT21BC200B	Screw-on 1/8" thru 5/8" flange - rotates 360 degrees	40
	CAT21CD1B	Under floor support to pedestal	20

Pre-Riveted Factory Assemblies for 2
	Catalog Number	Description	QTY Per Box
	CAT32528	Cable to acoustical tee bar	20
	CAT32BC	Screw-on 1/8" thru 1/2" flange	40
	CAT32BC200	Screw-on 1/8" thru 5/8" flange	20
	CAT3224	Hammer-on 1/8" thru 1/4" flange - rotates 360 degrees	40
	CAT3258	Hammer-on 5/16" thru 1/2" flange - rotates 360 degrees	20
	CAT32912	Hammer-on 1/2" thru 3/4" flange - rotates 360 degrees	20
	CAT32VF14	1/16" thru 1/4" vertical flange	40
	CAT32AF14	1/16" thru 1/4" Z purlin	40
	CAT324Z34	#12 thru 1/4", plain or threaded rod and 1/8" thru 3/8" flange	40
	CAT326Z34	3/8" plain or threaded rod and 3/8" thru 9/16" flange	40
	CAT32AB	Angle bracket	40
	CAT32CPNA	Longer leg angle bracket	50
	CAT32BCB	Screw-on 1/8" thru 1/2" flange rotates 360 degrees	20
	CAT32BC200B	Screw-on 1/8" thru 5/8" flange rotates 360 degrees	20
	CAT32CD1B	Under floor support to pedestal	20

4
	Catalog Number	Description	QTY Per Box
	CAT64BC	Screw-on 1/8" thru 1/2" flange	25
	CAT64BC200	Screw-on 1/8" thru 5/8" flange	25
	CAT6424	Mount rotates 360 degrees	25
	CAT6458	Mount rotates 360 degrees	25
	CAT64912	Mount rotates 360 degrees	25
	CAT64VF14	1/16" thru 1/4" vertical flange	25
	CAT64AF14	1/16" thru 1/4" Z purlin	25
	CAT64CPNA	Longer leg angle bracket	25
	CAT64AB	Angle bracket	25
	CAT64BCB	Screw-on 1/8" thru 1/2" flange rotates 360 degrees	25
	CAT64BC200B	Screw-on 1/8" thru 5/8" flange rotates 360 degrees	25
	CAT64CD1B	J-hook to 3/4" & 1" round or square pedestal	25

---

CableCat Pully

Features: Frees up the "second man" on cable pulling CAT32PLR accepts up to 20 four-pair cables (CAT64PLR - 40 pair cables) Complies with the TIA standard requirement by minimizing the pull force on the cable Maintains proper bend radius and protects cable during the installation Kit includes J-hook, pin, wheel and retainer When the job is complete, the pulley and pin assembly can be removed leaving the J-hook as a cable support The CAT32PLR pulley components can be used on any current design CAT32 J-Hook

Ordering Information
	Description	QTY Per Box
CAT32PLR	Pulley Kit - CAT32 2" J-hook, pin, wheel and retainer	10
CAT64PLR	Pulley Kit - CAT64 4" J-hook, pin, wheel and retainer	10

---

CableCat Adjustable Cable Support

Features: Up to 425 cables of 4-pair UTP or fiber optic - 4" or 6" dia. loop Provides proper support of Category 5, fiber optic and innerduct Variety of sizes and designs available to attach to virtually any structure Cost effective alternative to expensive cable tray Complies with UL, cUL, NEC and EIA/TIA requirements for structured cabling systems Suitable for air handling spaces (plenum)

Ordering Information
	Catalog Number	Description	QTY Per Box
	CAT425WM	Wall mount - Vertical surface	10
	CAT425	1/4" threaded rod or horizontal surface mount	10
	CAT425A6	3/8" threaded rod	10
	CAT42524SM	Hammer-on 1/8" - 1/4" flange	10
	CAT42558SM	Hammer-on 5/16" - 1/2" flange	10
	CAT425912SM	Hammer-on 9/16" - 3/4" flange	10
	CAT425BC	Screw-on 1/8" 1/2" flange (rotates 360 degrees)	10
	CAT425BC200	Screw-on 1/8" - 5/8" flange (rotates 360 degrees)	10
	CAT425AF14	Hammer-on 1/16" - 1/4" Z purlin	10
	CAT425VF14	Hammer-on 1/16" - 1/4" vertical flange	10
	CAT425CD1B	Under floor to pedestal	10

---

CableCat Vertical Backbone Cable Support

Features: Makes vertical cable pulling easier; locking mechanism opens during pull and re-engages when cable is released Accepts wide range of cable sizes: (80) 4-pair UTP, (10) 25-pair UTP, (1) each 100-pir through 600-pair Available as wall-mount (#CAT600WM) or strut-mount (#CAT600R) Strut-mount includes pre-riveted assembly that twist-locks into the strut Rounded edges prevent cable damage Valuable space savings withing telecom closets More versatile allowing future additions of cable runs Reduces installation time Allows cable installation to start at the bottom floor Galvanized finish for corrosion protection

Ordering Information
	Catalog Number	Description	QTY Per Box
	CAT600WM	Wall Mount	2
	CAT600R	Strut Mount	2
	CAT600RKIT	Strut mount kit with (1) 18" precut slotted strut & (4) CAT 600R	1
