MINI-COM Classic Series Faceplates
The Classic Series Faceplates, with their sleek design, work in all single gang outlet locations. The faceplates also work with wall board adapters, raceway mounting brackets and standard size single gang junction boxes. The heads of the screws are color matched to the faceplate for a clean and consistent look for non-labeled versions. Classic Series Faceplates with Labels provide an aesthetic solution for complete identification. Other Classic Series faceplates can be labeled easily with modular labels. Dedicated sloped faceplates provide improve bend radius control ensuring standards compliance. Dedicated sloped faceplates with icon slots provide an alternative method for jack identification. Horizontally oriented faceplates work well with horizontally mounted T70 raceway. When using Panduit raceway and faceplates together, color matching is guaranteed.
Technical Information | |
---|---|
Faceplate dimensions | Horizontal H x W x L = 0.22 x 2.75 x 4.50 in. (5.7 x 69.8 x 114.3 mm) Vertical H x W x L = 0.22 x 4.50 x 2.75 in. (5.7 x 114.3 x 69.8 mm) |
Mounting options | Screw holes with screw retention tabs, spaced for single gang openings, and works with Panduit wall board adapters (MWBA1 & MWBA-2G) |
Packaging | Supplied with two 1" long #6-32 screws and packaged 1 per bag, 10 per box. Bulk packages available, please consult catalog for part numbers. |
Key Features and Benefits | |
---|---|
Labels and label covers | Follows TIA/EIA-606 labeling standards |
Dedicated sloped version | Provides improved bend radius control Select styles available with icon slots |
Modularity | Accepts all MINI-COM copper and fiber modules; individual modules snap in and out |
Economical | Lower installed cost |
Sleek Design | Aesthetically pleasing look and feel |
Matches raceway faceplates | Consistent look and feel |
Faceplates are available with multiple module spaces for both vertical and horizontal applications. Each faceplate accept individual modules for both copper and fiber optic applications. Faceplates are flush mounted with a clean look and be available with or without labels. Dedicated sloped versions are available for improved bend radius control and decreased requirements in wall depth.
Vertical Faceplates with Labels
Two Module Space | Two Module Space Sloped | Three Module Space | Four Module Space | Six Module Space |
---|---|---|---|---|
CFPL2 | CFPSL2BLY | CFPL3 | CFPL4Y | CFPL6BLY |
![]() | ![]() | ![]() | ![]() | ![]() |
Vertical Faceplates
One Module Space | Two Module Space | Four Module Space |
---|---|---|
CFP1 | CFP2 | CFP4 |
![]() | ![]() | ![]() |
Horizontal Faceplates with Labels
Four Module Space Sloped |
---|
CFPHSL4 |
![]() |
Horizontal Faceplates
Two Module Space: | Four Module Space |
---|---|
CFPH2 | CFPH4 |
![]() | ![]() |
Icons *
Phone | Computer |
---|---|
CIP-C | CID-C |
![]() | ![]() |
Colors
Substitute:- IW = Off White
- EI = Electrical Ivory
- IG = International Gray
- WH = White
- BL = Black
- OR = Orange
- RD = Red
- BU = Blue
- GR = Green
- YL = Yellow
- VL = Violet
