The CH6000, DVR1800, and MPU3200 Series are solid state, remote programmable, digital announcers with pass through ability that answers up to 3 lines. Available in 2, 4, 6, 8, 12, and 32 minute recording times.
The CH6000 Series
The CH6000 is a solid state, remote programmable, digital announcer with pass through ability that answers up to 3 lines. It can be used simultaneously for information on hold.
- Multiple Lines: Answers 1 - 3 lines simultaneously and each line can be turned on/off separately to allow calls to pass through. All lines may have the same message or each a different message. All messages can be down-loaded with one call. Each line can be set separately to answer on 1 to 9 rings. In the ring through mode, the caller hears on-hold programming while the phone is ringing through to the user. Also, the handler message can be repeated and a time interval set between repeats. The Call Handler allows special phone company services, such as caller ID.
- Call Forwarding: In night answer mode, line 1 can be set separately to forward calls to another line. Line 1 routes them out through line 2.
- Built-in On-Hold: Equipped with a built-in on-hold capability. The on hold message can be recorded locally or remotely during the same call that other messages are recorded. On hold shares the nonvolatile flash memory with the Handler messages and night answer messages. The on hold message can also be output to the on hold port of the telephone system.
- Night Answer: Can be programmed for night answer with 24 hour clock. In night answer the unit answers the call, plays a night answer message, and hangs up, or forwards the call as programmed.
- Auto Pass Through: In the event of a power failure, the unit automatically takes itself off line so calls can be answered without interference. Auto Connect: Anytime a line is not occupied with an incoming call, users may call out. Unit automatically removes itself from the line.
- Auto Hang-up Detect: Anytime a caller hangs up before the call is answered by user, the unit detects the hang-up and instantly resets for the next call.
- Zero Gap: When recording a production, the unit records the silence at the start and end of recording. However, the on board computer has the intelligence to go back and delete the silence leaving zero gap in the loop.
- Call Counter: Each line has 3 counters that can count up to 99,999 calls and can be retrieved either locally or remotely.
- Volume Control: Unit has a volume control that can be changed remotely or locally. Local control of the volume can be deactivated.
- Plug and Play: Dealer can preload the unit with messages in flash memory and ship the unit ready to plug and play.
- Verbal Prompting:Assists with remote loading and retrieving call counts.
- Security CodeThere is a dealer-definable 5 digit security code with"three times your out" software to prevent unauthorized entry. Code is held permanently in flash memory.
- Brownout ProtectionIn the event of a brownout, a drop in the power will not damage electronics or cause improper operation. Also, recordings in flash memory are unaffected by brownouts.
The Call Handler can answer up to 3 telephone lines and give a pre-answer message. At the end of the message, the Call Handler will ring through to the telephone/telephone system. During the ring time the unit has the ability to play on hold programming. Most businesses can use it to pre-condition callers buying thoughts.
- Information Lines
Flash memory and 64K sampling makes this an excellent multiple port digital announcer with endless uses. (ACD/UCD) Announcements - Movie Theatres - Information Lines -Weather Lines.
- Night Answer
The Call Handler has a clock built in, so it can automatically go into night answer mode at a preprogrammed time. In night answer mode the unit answers the call, plays a night message and hangs up or forwards the call as programmed.
- Call Filtering
In applications where a business receives multiple calls requesting routine information, the Call Handler can be used to give callers this information. This reduces the number of routine information calls employees have to answer.
|Sampling Rate||64 kbps (effective 96 kbps)|
|Recording Times||2 minutes to 32 minutes (model dependent)|
|Flash Memory||Nonvolatile, unaffected by power interruptions of any duration|
|Recording Method||Remotely from any touch tone phone or locally by using the key pad and following the LCD instructions. Unit will down load messaging from a handset or tape player. Recording is automatically started and stopped with 4 seconds of silence|
|Power Source||12V AC UL approved adaptor (included)|
|Ring Detection||AC Ring, DC Ring, square wave ring|
|Trunk Line Type||Loop start or ground start and will automatically accommodate normal or reverse polarity lines|
|Serial Port||Unit uses a standard RS232 port for communications to printers and other devices|
The DVR1800 Series
The DVR 1800 unit is a solid state, remote programmable, digital recorder that stores audio messages for answer only applications like ACD/UCD, information lines, and night answer.
- Flash Memory – A technological breakthrough gives the DVR 1800 the memory of the future. This new, nonvolatile memory means the recording will never be lost due to loss of power. Flash memory eliminates the need for back-up batteries.
- Crystal-Clear Sound Quality – 64 kbps sampling assures the highest quality playback of your on-hold message.
- Remote – All program elements, including audio production, volume level and setting of security code can be downloaded remotely from a touch-tone telephone. First time programming can be done at the dealer’s facility and the DVR can be sent to the customer’s site fully loaded.
- Verbal Prompting – A human voice guides users through operation of the on-hold unit. This makes the DVR 1800 the most userfriendly unit available.
- Adjustable Rings – The number of rings for 1 to 12 to meet each user’s requirements.
- Call Counter – The DVR 1800 counts the number of calls it receives. Knowing the number of calls the unit receives gives the business important information. The counter can be reset at any time.
- Automatic Disconnect – The DVR disconnects immediately after message completion, or upon premature caller hang up. In either case, the DVR is immediately available to answer the next call.
- Assured Security – A personal 5-digit security code guarantees security for the user and programmer.
- Two Models to Choose From – DVR 1800 with handset jack gives you the flexibility to record locally from a tape player or the handset jack. DVRT 1800 with the above features plus a programmable time of day clock to disable call answer during business hours.The clock can be manually disabled at any time with the mode switch.
A Few Uses For the DVR 1800:
- ACD/UCD Groups - as a greeting or memo announcement.
- Auto Attendants - as a greeting or memo announcement.
- Information Announcements - weather conditions, schedules, homework hot lines, after hours message, etc.
Feature Description Sampling Rate 64 kbps (effective 96 kbps) Recording Times 2 minutes to 47 minutes (model dependent) Flash Memory Nonvolatile, unaffected by power interruptions, no matter how long the unit is without power Recording Method Remotely from any touch-tone telephone or locally via cassette player or handset Security Code There is a dealer-definable 5 digit security code to prevent unauthorized entry. Code is held permanently in flash memory Power Source 12V AC adapter, included Audio Output 600 Ohm & 8 Ohm (Note: 8 Ohm output has a 5 watt amplifier.) Wiring 2 wire RJ-I I type, included Verbal Prompting Assists with remote loading Dimensions 7.25" H x 7.50"W x 2.0" D Ring Detection AC Ring and Square Wave Ring Weight 4 lb. (Boxed)
The MPU3200 Series
The model 3200 is the ultimate in solid state digital message repeaters.This unit features a built in tape player for fool proof message downloading, along with flash memory and the ability to play up to six different messages.
- Flash Memory – A technological breakthrough gives the 3200 the memory of the future. This new, nonvolatile memory means the recording will never be lost due to loss of power. Flash memory eliminates the need for back-up batteries.
- Tape Mechanism – To guarantee a perfect download, our system uses the highest quality tape drive in the industry.This drive is built to accompany high end stereo equipment, not the lower quality products found in answering machines.The unit loads your customized messages on speed every time.
- Crystal-Clear Sound Quality – 64 kbps sampling assures the highest quality playback of your messages.
- Multiple Messages, Multiple Message Length – Record up to six different messages of varying length, as long as the total message length does not exceed memory.
- Zero Gap – Most digital systems listen for silence to know when to stop recording.This leaves an irritating gap of silence between the end of your message and the beginning of the next message.The 3200 records the silence gap, but the on-board computer has the intelligence to go back and delete the silence leaving Zero Gap in the loop.
- Verbal Prompting – Our unit is the easiest system to operate.A human voice leads you through installation of the messages.When power is supplied to the system it says, “Please insert your cassette tape with the label facing you and close my door.” When this is done you will hear, “I am loading your messages now.” At the end of the downloading the machine lets you know everything is okay by saying, “I have successfully digitized your tape.”
- Trade Show Displays
- Corporate Lobbies
- Restaurant & Bank Drive Thrus
- Interactive Kiosks
- Alarm Systems
- Theme Park Announcements
- Intercom Announcements
Feature Description Dimensions 5.25 X 8.5 X 5 Weight 6 Sampling 64 kbps (effective 96 kbps) Recording Time 2 minutes up to 47 minutes Memory Nonvolatile, unaffected by power interruptions, no matter how long the unit is without power. Power Source 12V AC adapter, included. Audio Output 600 Ohm & 8 Ohm Other Verbal Prompting Assists with Loading
