PRYME Radio Products offers a full line of remote speaker microphones, mini-boom mics, throat mics, earphones, surveillance kits, and other audio accessories for most major brands of portable two-way radios. PRYME products have applications in security, retail, business, industrial, and public safety environments. More than just offering microphones, PRYME offers complete solutions for your audio product needs.

PRYME Radio Products has been serving the commercial, industrial, and amateur two-way radio industry since 1995. Quality and Service coupled with Selection and Low Cost, PRYME Radio Products is the perfect solution for all of your audio accessory needs. PRYME Radio Products prides itself on innovation, reliability, affordablility, and practicality. When it comes to audio accessories for two-way radios, PRYME is your one stop solution.


Audio Solutions Product Line

OBSERVER SPM-100 Series - Light Duty Speaker Microphone

The OBSERVER SPM-100 series is a lightweight, compact remote speaker microphone designed for use in light-duty applications. Each microphone features a high-quality electret condenser-style microphone element that produces excellent transmitted audio clarity. The OBSERVER SPM-100 series is meant to be worn on the user's lapel, duty belt, or shoulder epaulet. It is secured to the user's clothing by way of a large, metal-reinforced clip which can be rotated 360 degrees.

The OBSERVER SPM-100 series features a powerful, built-in speaker, which should provide loud enough receive audio for all but the noisiest of environments. However, for additional privacy and security. The OBSERVER SPM-100 series features a built-in 3.5mm earphone jack for using an external earphone, such as the EH-100 or EH-1000 series.

Features:

  • Lightweight, compact remote speaker microphone
  • High-quality electret condenser-style microphone element that produces excellent transmitted audio clarity
  • Features a large, metal-reinforced clip which can attach the microphone to the user's lapel, duty belt, or shoulder epaulets
  • The powerful, built-in speaker has loud enough receive audio for all but the noisiest of environments
  • For additional privacy and security, the OBSERVER SPM-100 series also has a built-in earphone jack, allowing operation through an optional remote earphone
  • Click here to view Pryme's SPM-100 Series Light Duty Remote Speaker Mic. PDF


RESPONDER SPM-300EB Series - Medium Duty Lapel Microphone

The RESPONDER SPM-300EB series is a rugged lapel mic and in-line earphone for two-way radio use. The unit features a high-quality electret condenser microphone and PTT combo in a rugged polycarbonate housing with a metal clip. The microphone easily clips to the user's lapel or collar, and the conveniently located Push-To-Talk makes it a snap to use. For even more durability and longevity, the RESPONDER SPM-300EB series features a heavy-duty polyurethane jacketed, coiled mic cable.

The speaker on the RESPONDER SPM-300EB series is held in place by a convenient rubber earhook. The earhook provides additional support and also makes the RESPONDER SPM-300EB series extremely comfortable to wear. The low profile nature of the RESPONDER SPM-300EB series makes it perfect for all light and medium duty applications, such as surveillance and "black tie" security. The RESPONDER SPM-300EB series microphones are one of the most comfortable lapel surveillance microphones on the market today!

Features:

  • Rugged lapel mic and in-line earphone
  • Extremely low profile
  • Soft rubber earhook holds the earphone in place even during strenuous activity and is extremely comfortable to wear
  • High-quality electret condenser mic element produces excellent transmitted audio
  • Rugged polycarbonate housing for maximum durability
  • Heavy-duty polyurethane jacketed, coiled mic cable
  • A large metal clip secures the mic/PTT to the user's lapel or collar
  • Click here to view Pryme's SPM-300EB Series Medium Duty Lapel Microphone PDF


RANGER SPM-400A Series - Medium Duty Mini-Boom Microphone

The RANGER SPM-400A series mini-boom headsets include an in-the-ear speaker and a rubber-covered earloop design that adjusts to comfortably fit either the right or left ear of any user. The entire headset/speaker assembly is made of durable polyurethane and rubber for maximum durability. The RANGER SPM-400A series is perfect for many different medium-duty uses, including retail stores, bicycle operation, security, business and industrial, and more.

The unit features an in-line Push-to-Talk switch that can be clipped to the user's lapel or belt, or the unit can be keyed remotely using an optional remote cord. This remote PTT plugs right into the RESPONDER SPM-400A series and allows you to operate with a "fingertip PTT" by dropping the cable down your sleeve. The remote PTT is also great for bicycle operation because it can be secured to your handlebars for increased safety!

Features:

  • Rugged mini-boom headset and earphone
  • Extremely comfortable and lightweight. Adjusts to fit either the left or the right ear
  • Soft rubber earhook holds the headset in place even during strenuous activity
  • High-quality electret condenser mic element produces excellent transmitted audio
  • Rugged polycarbonate and rubber construction for maximum durability
  • Heavy-duty polyurethane jacketed, coiled mic cable
  • Click here to view Pryme's SPM-400A Series Medium Duty Mini-Boom Mic. PDF


HIGHWAY SPM-800 Series - Meium Duty In-Helmet Microphone

For motorcyclists, racing enthusiasts, or any other user who needs to operate a two-way radio while wearing head protection, the HIGHWAY SPM-800 series mic represents a big step forward. The HIGHWAY SPM-800B series is an in-helmet boom microphone and speaker system perfect for those wearing half-helmets. For users whose safety demands full face helmets. The HIGHWAY SPM-800F series is an in-helmet mic/speaker system. The electret mic systems reduce background noise to an absolute minimum. Both microphones feature a large, rubber-covered Push-To-Talk button that can be secured to handlebars or held in the palm of the hand and is easy to find and operate, even while wearing heavy gloves!

The HIGHWAY SPM-800B/800F series installs in the helmet pads using only VELCROŽ brand touch fastener (included) - you need not drill any holes in the helmet which might potentially weaken it. Either system is fully modular and removable from the helmet when not needed.

Features:

  • Lightweight in-helmet motorcycle mic system
  • Available to fit either open faced (SPM-800B) or full faced (SPM-800F) helmets
  • Designed for use in light-duty applications such as Security, and Recreation
  • Powerful, in helmet speakers allow the user to hear radio transmissions over road noise
  • High-quality electret condenser mic element produces excellent transmitted audio
  • Handlebar Mounted Push-To-Talk switch for easy use
  • Durable construction using polyurethane cable, high impact polycarbonate, and rubber
  • Installs into the helmet using only VELCROŽ brand touch fastener. No drilling of holes is required
  • Completely modular. The mic system can be easily disconnected from the motorcycle when the user dismounts
  • Click here to view Pryme's SPM-800 Series Medium Duty In-Helmet Mic. PDF


UNDERCOVER SPM-1000 Series - Light Duty Acoustic Tube Surveillance Kit

The UNDERCOVER SPM-1000 series is a single-wire acoustic tube earphone for two-way radios. The unit is quite similar to more expensive surveillance style earphones made by other manufacturers. It includes a high-quality acoustic ear tube made out of durable surgical grade tubing for great comfort and a low-profile look. The UNDERCOVER SPM-1000 series also features heavy grade industrial polyurethane jacketed cable for maximum life in the field. The cabling can be easily concealed under a sport coat or other clothing. For privacy and security, there is no better choice.

When you need to talk back, the UNDERCOVER SPM-1000 series features an in-line jack for connecting microphone and Push-To-Talk options. A number of different microphone and PTT option are available, one of which is bound to be perfect whatever the situation. Adding a microphone option effectively converts your one-wire earphone into a two-wire surveillance system.

Features:

  • Listen-only surveillance style earphone for use with two-way radios
  • Acoustic tube earphone provides extreme comfort and a low-profile look
  • Durable construction featuring surgical grade tubing and heavy industrial polyurethane jacketed cable for maximum life in the field
  • Can be easily concealed under a sport coat, jacket, or other clothing
  • When you need to talk back, the UNDERCOVER SPM-1000 series features an in-line jack for connecting microphone and Push-To-Talk accessory options. Adding a microphone option effectively converts your one-wire earphone into a two-wire surveillance system
  • Includes one Flexible Open Ear Insert, as well as a variety of other accessories
  • Modular transducer, cable and earphone makes the unit user serviceable for an even longer lifespan
  • Click here to view Pryme's SPM-1000 Series Light Duty Acoustic Tube Surveillance Kit PDF


MIRAGE SPM-1300 Series - Medium Duty Lapel Microphone with Acoustic Tube Earphone

The professional quality lapel microphone, the MIRAGE SPM-1300 series, combines all the comfort of Pryme's surveillance kits with the ease and utility of a lapel microphone. The acoustic tube earphone provides private listening, is low profile, and can be worn for hours on end. The in-line microphone/PTT is meant to be clipped to the user's lapel and can be operated quickly and conveniently. The MIRAGE SPM-1300 series is made with high-impact polycarbonate and high quality polyurethane jacketed cable for maximum durability.

Features:

  • Rugged lapel mic with surveillance style acoustic tube earphone
  • The clear eartube is low profile and provides outstanding receive audio
  • High-quality electret condenser mic element produces excellent transmitted audio
  • Rugged polycarbonate housing for miximum durability
  • Heavy-duty polyurethane jacketed, coiled mic cable
  • A large metal clip secures the mic/PTT to the user's lapel or collar
  • Conveniently located Push-To-Talk for easy use


GLADIATOR SPM-1500 Series - Medium Duty Throat/Tactical Microphone

The GLADIATOR SPM-1500 series throat microphone is a perfect solution for high noise and tactical environments. The dual electret condenser microphones pick up the user's voice directly from vocal chord vibrations, cutting down on ambient and near-by noise, while the acoustic tube earphone provides privacy. The GLADIATOR SPM-1500 series features a large PTT which can be easily activated even while wearing heavy gloves.

Features:

  • Professional quality throat microphone with earphone
  • Reduces background noise by picking up the sound of the user's voice directly from vocal cord vibration
  • Dual microphone system provides the highest quality transmit audio possible
  • Adjusts to comfortably fit most users
  • Heavy duty construction featuring polyurethane cable, rubber, and high impact poly carbonate
  • Uses a clear, acoustic tube style surveillance earphone made of heavy grade surgical tubing
  • Large PTT button secures to the user's lapel or belt by way of a heavy duty clothing clip
  • Modular microphone cables make for easier field repair


STEALTH SPM-2000 Series - Medium Duty Acoustic Tube Surveilllance Kit

For public safety, security, government, and other users who need dependable, low profile communications, the STEALTH SPM-2000 series fits the bill perfectly. The unit is an acoustic tube surveillance kit including microphone and earphone for use with portable two-way radios. It is meant to be worn under the user's clothing with the microphone dropped down the user's sleeve or clipped to the lapel. The clear acoustic tube style earphone makes the STEALTH SPM-2000 series a complete low-profile solution.

In addition to being stealthy, the STEALTH SPM-2000 series is also durable. It has heavy-duty microphone cable with a strong polyurethane jacket and superior strain relief compared to other similarly priced products. The microphone housing is also made of high-quality polycarbonate for long life in the field. The entire earphone assembly is field repairable and a full line of replacement parts and optional earbuds is available.

Features:

  • Two-wire surveillance kit with acoustic tube earphone and built-in microphone/PTT
  • Can be easily concealed under clothing
  • The clear eartube is low profile and provides outstanding receive audio
  • Features heavy-duty microphone cable with a strong polyurethane jacket and superior strain relief
  • The mic housing is made of high-quality polycarbonate for long life in the field
  • The entire earphone assembly is field repairable and a full line of replacement parts and optional earbuds is available
  • Includes one Flexible Open Ear Insert FREE, as well as a variety of other accessories
  • Click here to view Pryme's SPM-2000 Series Medium Duty Acoustic Tube Surveillance Kit PDF


SONIC SPM-3000 Series - Medium Duty Low Profile Surveillance Kit

For additional comfort, privacy and covert operation, the SONIC SPM-3000 series delivers. Like Pryme's other surveillance kits, the SONIC SPM-3000 series has a soft acoustic tube earphone that is comfortable enough to wear for hours on end. It also features a micro miniature speaker transducer which is worn behind the user's ear, making the earphone nearly invisible. The in-line microphone/PTT can be clipped to the user's lapel or worn under clothing for additional stealth.

Features:

  • Innovative, low profile desing makes the SONIC SPM-3000 series one of the most concealable surveillance kets available
  • Rugged lapel mic with in-line acoustic tube earphone
  • Can be easily concealed under clothing
  • The clear eartube features an extremely small speaker-transducer which can be easily concealed behind the ear and provides outstanding receive audio
  • Features heavy-duty microphone cable with a strong polyurethane jacket and superior strain relief
  • The mic housing is made of high-quality polycarbonate for long life in the field


LOOKOUT EH-100 Series - Light Duty Earphone (Listen Only)

Pryme's innovative over-the-ear earphone is available for your two-radio listening convenience. The LOOKOUT EH-100 series features the same rubber covered ear loop that provides hours of comfortable operating as an integrated part of the boom and lapel microphones, and is now available as a stand alone unit! These earphones provide comfort, privacy, and convenience.

Features:

  • Light duty, listen-only earphone
  • Soft rubber earhook holds the earphone in place even during strenuous activity
  • Extremely comfortable and can be worn for long periods of time
  • Heavy-duty polyurethane jacketed, coiled mic cable
  • Adjusts to fit either the left or right ear
  • Versions are available with both long cable (to plug directly into the radio) or short cable (to plug into a remote speaker microphone, such as the SPM-100 or SPM-1100)


RECON EH-1000 Series - Light Duty Surveillance Earphone (Listen Only)

The quality and comfort of Pryme's acoustic tube surveillance kits is now available in the RECON EH-1000 series, listen-only earphone. The RECON EH-1000 series features a heavy grade industrial jacketed cable for maximum life in the field and a surgical grade acoustic tube earphone for listening privacy and convenience.

Features:

  • Listen-only surveillance style earphone for use with two-way radios
  • Acoustic tube earphone provides extreme comfort and a low-profile look
  • Durable construction featuring surgical grade tubing and heavy industrial polyurethane jacketed cable for maximum life in the field
  • Can be easily concealed under a sport coat, jacket, or other clothing
  • Includes on Flexible Open Ear Insert FREE, as well as a variety of other accessories
  • Modular transducer, cable, and earphone makes the unit user serviceable for an even longer lifespan
  • Versions are available with both long cable (to plug directly into the radio) or short cable (to plug into a remote speaker microphone, such as our SPM-100 or SPM-1100)


Audio Accessory Adapters

Pryme's rugged adapters allow you to use common after market microphones on two-way radios with "unique" connectors. Pryme's adapters are fully compatible with any specified PRYME audio accessory, as well as many OEM and aftermarket audio accessories by other companies. Pryme audio adapters are made out of rugged high-impact polycarbonate and are built to outlast your radio.

Features:

  • Adapts your radio's multi-pin audio accessory connector use simple one or two pin accessories
  • Directly replaces OEM brand audio accessory adapters
  • Made of durable high-impact polycarbonate and rubber
  • Locks to the radio using a mounting screw
  • Rubber gasket seals and protects the microphone connector when no audio accessory is in use
Specifications:
  • PA-BDN6676: adapts Motorola HT1000/XTS3000 to fit PRYME x13 connector microphones
  • PA-HLN9716: adapts Motorola HT750/HT1250/HT1550 to fit PRYME x03 connector microphones
  • PA-HLN9717: adapts Motorola HT750/HT1250/HT1550 to fit PRYME x13 connector microphones


Radio-to-Connector Cross Reference

Each PRYME two-way radio accessory is made with a variety of connectors to match specific radio models. Below is a chart to find the connector to match your current radio. Simply locate your current radio manufacturer and model in the left column. The connector in the corresponding right column is the precise connector model to use when ordering your Pryme accessory.

EXAMPLE:

If you currently own an EF Johnson 5100 two-way radio and are interested in purchasing an SPM-1500 series Medium Duty Throat Microphone you will need to order one of the following choices --

  • a. SPM-1513 along with the required adapter, PA-BDN6676
  • b. SPM-1523
  • c. SPM-1523QD

(Click here to open a second browser with a table of the following connector types, with images.)

Quick Jump Table Links:

EF Johnson

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
(Stealth)
x13 + PA-BDN6676x23 -or- x23QD
5000
x13 + PA-BDN6676x23 -or- x23QD
5100
x13 + PA-BDN6676x23 -or- x23QD
7700
x13 + PA-BDN6676x23 -or- x23QD

Icom

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
IC-F3nonex00
IC-F3Gnonex00IL
IC-F3GSnonex00IL
IC-F3Snonex00
IC-F4nonex00
IC-F4Gnonex00IL
IC-F4GSnonex00IL
IC-F4Snonex00
IC-F11nonex00IL
IC-F21nonex00IL
IC-F30Gnonex10 -or- x10QD
IC-F31nonex00IL
IC-F31GSnonex10 -or- x10QD
IC-F31GTnonex10 -or- x10QD
IC-F40Gnonex10 -or- x10QD
IC-H2nonex00
IC-H6nonex00
IC-J12nonex00
IC-M5nonex00
IC-U12nonex00
IC-U16nonex00

Kenwood

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
TK-208nonex01
TK-220nonex01
TK-240nonex01
TK-240Dnonex01
TK-248nonex01
TK-250nonex01
TK-260nonex01
TK-260Gnonex01
TK-270nonex01
TK-270Gnonex01
TK-272Gnonex01
TK-280nonex11 -or- x11QD
TK-290nonex11 -or- x11QD
TK-308nonex01
TK-320nonex01
TK-340nonex01
TK-340Dnonex01
TK-348nonex01
TK-350nonex01
TK-353nonex01
TK-360nonex01
TK-360Gnonex01
TK-370nonex01
TK-370Gnonex01
TK-372Gnonex01
TK-380nonex11 -or- x11QD
TK-390nonex11 -or- x11QD
TK-430nonex01
TK-431nonex01
TK-480nonex11 -or- x11QD
TK-481nonex11 -or- x11QD
TK-2100 (Pro-Talk)nonex01
TK-2102 (Pro-Power)nonex01
TK-2130 (ProTalk XLS)nonex01
TK-2140nonex11 -or- x11QD
TK-2160nonex01
TK-3100 (Pro-Talk)nonex01
TK-3101 (FreeTalk XL)nonex01
TK-3102 (Pro-Power)nonex01
TK-3130 (ProTalk XLS)nonex01
TK-3131 (Free Talk XLS)nonex01
TK-3140nonex11 -or- x11QD
TK-3160nonex01

Maxon

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
Legacy PL1145x00 + Maxon ACC-506x04
Legacy PL2215Px00 + Maxon ACC-506x04
Legacy PL2245x00 + Maxon ACC-506x04
Legacy PL2245Px00 + Maxon ACC-506x04
Legacy PL2415x00 + Maxon ACC-506x04
Legacy PL2445x00 + Maxon ACC-506x04
Legacy PL5151x00 + Maxon ACC-506x04
Legacy PL5161x00 + Maxon ACC-506x04
Legacy PL5164x00 + Maxon ACC-506x04
SL25nonex00
SL55nonex00
SL55+x00 + Maxon ACC-501none
SL100x00 + Maxon ACC-506x04
SL100Kx00 + Maxon ACC-501none
SP120nonex00
SP130nonex00
SP140nonex00
SP200x00 + Maxon ACC-506x04
SP200Kx00 + Maxon ACC-506x04
SP210x00 + Maxon ACC-506x04
SP-300x00 + Maxon ACC-501none
SP310x00 + Maxon ACC-501none
SP320x00 + Maxon ACC-501none
SP330x00 + Maxon ACC-501none
SP340x00 + Maxon ACC-501none

Motorola

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
CP100nonex03
CP150nonex03
CP200nonex03
CT150nonex03
CT250nonex03
CT450nonex03
CT450LSnonex03
EX500nonex43 -or- x43QD
EX600nonex43 -or- x43QD
GL2000nonex43 -or- x43QD
GP68nonex03
GP88nonex03
GP140x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP300nonex03
GP308nonex03
GP320x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP328x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP328PLUSnonex43 -or- x43QD
GP329x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP338x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33
GP338Plusnonex43
GP339x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33
GP340x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP344nonex43 -or- x43QD
GP350x03 + Motorola HLN9482none
GP360x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP380x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP388nonex43 -or- x43QD
GP640x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP650x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP680x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP900x13 + PA-BDN6676x23 -or- x23QD
GP1280x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
GP2000nonex03
GP9000x13 + PA-BDN6676x23 -or- x23QD
GTInonex03
GTXnonex03
HT750x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33
HT1000x13 + PA-BDN6676x23 -or- x23QD
HT1250x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
HT1250LSx03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
HT1550x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
HT1550XLSx03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
HT600x53 + Motorola NTN5075-MTnone
JT1000x13 + PA-BDN6676x23 -or- x23QD
LTS2000nonex03
MT1000x53 + Motorola NTN5075-MT
-or-
x53 + Motorola NTN5598
none
MT2000x13 + PA-BDN6676x23 -or-x23QD
MTS2000x13 + PA-BDN6676x23 -or- x23QD
MTX Classicx53 + Motorola NTN5075-MTnone
MTX800x53 + Motorola NTN5075-MT
-or-
x53 + Motorola NTN5598
none
MTX838x13 + PA-BDN6676x23 -or- x23QD
MTX850x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
MTX850LSx03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
MTX900x53 + Motorola NTN5075-MT
-or-
x53 + Motorola NTN5598
none
MTX950x03 + PA-HLN9716x33 -or- x33QD
MTX-960x13 + PA-BDN6676x23 -or- x23QD
MTX8000x13 + PA-BDN6676x23 -or- x23QD
MTX8250x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
MTX8250LSx03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
MTX9000x13 + PA-BDN6676x23 -or- x23QD
MTX9250x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
MTXLSx13 + PA-BDN6676x23 -or- x23QD
P040nonex03
P080nonex03
P110nonex03
P1225nonex03
P1225LSnonex03
P200x53 + Motorola NTN5075-MTnone
PRO3150nonex03
PRO5150x03 + PA-HLN9716x33 -or- x33QD
PRO5151Elitenonex43 -or- x43QD
PRO5350x03 + PA-HLN9716x33 -or- x33QD
PRO5450x03 + PA-HLN9716x33 -or- x33QD
PRO5550x03 + PA-HLN9716x33 -or- x33QD
PRO5750x03 + PA-HLN9716x33 -or- x33QD
PRO7150x03 + PA-HLN9716x33 -or- x33QD
PRO7350x03 + PA-HLN9716x33 -or- x33QD
PRO7450x03 + PA-HLN9716x33 -or- x33QD
PRO7550x03 + PA-HLN9716x33 -or- x33QD
PRO7750x03 + PA-HLN9716x33 -or- x33QD
PRO9150x03 + PA-HLN9716x33 -or- x33QD
PTX700x03 + PA-HLN9716
-or-
x13 + PA-HLN9717
x33 -or- x33QD
PTX760x03 + PA-HLN9716x33 -or- x33QD
PTX780x03 + PA-HLN9716x33 -or- x33QD
Saberx53 + Motorola NTN5213
-or-
x53 + Motorola NTN5664
none
Saber IIx53 + Motorola NTN5213
-or-
x53 + Motorola NTN5664
none
Saber IIIx53 + Motorola NTN5213
-or-
x53 + Motorola NTN5664
none
SP10nonex03
SP21nonex03
SP50nonex03
Visar Seriesnonex13
XTN446nonex03
XTN500nonex03
XTN600nonex03
XTS2500x13 + PA-BDN6676x23 -or- x23QD
XTS3000x13 + PA-BDN6676x23 -or- x23QD
XTS3500x13 + PA-BDN6676x23 -or- x23QD
XTS5000x13 + PA-BDN6676x23 -or- x23QD

Relm

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
RPU416nonex01
RPV416nonex01

Ritron

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
JOBCOM JMXnonex00
JOBCOM MBXnonex00
Patriot RTXnonex00
Patriot SSTnonex00

Vertex

RadioConnector + Required AdapterSpecific Connector (No Adapter Needed)
Vertex VX-10nonex02
Vertex VX160nonex22 -or- x02
Vertex VX180nonex22 -or- x02
Vertex VX-200nonex00
Vertex VX210nonex22 -or- x02
Vertex VX210Anonex22 -or- x02
Vertex VX-300nonex02
Vertex VX-400nonex22 -or- x02
Vertex VX-500nonex00
Vertex VX-510nonex00
Vertex VX-600nonex12 -or- x12QD
Vertex VX-800nonex12 -or- x12QD
Vertex VX-900nonex12 -or- x12QD
Vertex VXF-1nonex02


Click here for a complete table and images of the above connector types.

VELCROŽ is a registered trademark of Velcro Industries B.V.

NOTE: Viewing PDF documents requires the free Adobe® Reader® version 5.0 or greater.If you don't already have it installed, you will need to download and install it before using PDF documents.
Get Adobe Reader
